Model
| R36 |
Standards
| Wired: IEEE 802.3 (10Base-T) IEEE 802.3u (100Base-TX)
Wireless: IEEE 802.11, IEEE 802.11g, IEEE 802.11n |
Physical
| 1 x 10/100Mbps WAN Port
1 x 10/100Mbps LAN Port
1 x detachable external 5dBi antenna
1 x Reset button
1 x WPS Security Key
1 x USB Port |
Management
| Web-base management interface
Remote management
SNTP time synchronize |
Output Power
| 802.11b: 27dBm ± 2dBm
802.11g: 25dBm ± 2dBm
802.11n: 25dBm ± 2dBm |
Sensitivity
|
11n
|
20MHz
| MCS7: -71 MCS0: -90 |
40MHz
| MCS7: -69 MCS0: -88 |
11g
| 54Mbps: -75 6Mbps: -92 |
11b
| 11Mbps: -90 1Mbps: -95 |
Data Rate
| 802.11n ( 40MHz ): up to 150Mbps
802.11n ( 20MHz ): up to 72Mbps
802.11g: 54,48,36,24,18,12,9,6Mbps
802.11b: 11,5.5,2,1Mbps |
Wireless Mode
| WISP
Bridge
Router |
Operating Frequency
| FCC: 2412~2462MHz (Ch1~Ch11)
ETSI: 2412~2472MHz (Ch1~Ch13)
Japan: 2412~2484MHz (Ch1~Ch14) |
Security
| Access Control Policy
MAC filter
DMZ Host
SSID Broadcast disable
Wireless MAC address Filtering
WEP Encryption
WPA-/W PA2-PSK (Pre-shared Key)
WPA/W PA2 Enterprise mode (802.1x)
WiFi Protected Setup (WPS) |
Router
| Shares high speed cable/xDSL Internet connection
Static Routing
VPN Pass through
NAT
802.11e WMM
IGMP Proxy
Dual SSIDs |
Temperature
| Operating: 0ºC to 40ºC (32ºF to 104ºF)
Storage: -20ºC to 60ºC (-4ºF to 140ºF) |
Humidity
| Operating :10% to 85% Non-Condensing
Storage: 5% to 90% Non-Condensing |
Dimensions
| 93 x 70 x 26mm |
Weight
| 74g |
Power Input
| 12V/1A |
3G Functions
| 3G budget Control with Email warning
( Support Pre-pay and Post-pay )
Dual Wan backup
Remote Access Control by 3G WAN |
Compatible 3G USB Modem
| ALFA Onyx3G
ALFA Fly3G
Huawei E220
Huawei E169/169G/169U
Huawei E219
Huawei D02
Huawei D21
Huawei D22
Huawei D23
Huawei D31
Huawei ET128
Huawei D12HW
Huawei D12LC
Huawei D21LC
Huawei E1762
Huawei E1552
Huawei E1782
Huawei E1552
Huawei E1782
Huawei E156G
Huawei E177
Asus T500
SonyEricsson MD300
Qisda H21(single)
ZTE MF626
ZTE MF627
ZTE MF628
ZTE AC2726
ZTE MF636
ZTE MF637
ZTE AC2736
ZTE MF631
ZTE MF180
PROLINK PHS100
PROLINK PHS300
PROLINK PHS101
DoCoMo A2502
SoftBank C01LC
Sierra 598U
C-MOTECH U300
Qisda H21(dual)
EpiValley 8089
i-mobile U3300
BandLuxe C180
Option Icon 225
Dlink DWM-156
NOKIA CS-15
Royaltek Q110
CSL U1-TF |
